Technical Features

The utility model has the advantages of simple operation, portability, accurate results, better man-machine interaction and user experience, and can meet the requirements of users for rapid disposal and continuous monitoring.

Application

Pre-hospital emergency, emergency, respiratory, anesthesia, surgery, ICU, neonatology

Intubation – Severely non-spontaneous and semi-spontaneous breathing mechanically ventilated patients.

Non-intubation – Spontaneous breathing patients are tested by sampling through masks and nasal oxygen tubes.

Specification

Parameters Range Accuracy

CO2 0~40 mm Hg ±2mmHg

41~70 mm Hg ±(5% of reading)

71~100 mm Hg ±(8% of reading)

101~150 mm Hg ±(10% of reading)

*Above 80 breaths per minute *±(12% of reading)

RR 0-150bpm ±1bpm

SpO2 0-100% 0-69%  undefined

70-100%±4%

PR 30-240bpm ±3bpm

N2O 0-100% ±(2%+2% of reading)

HAL 0-8%

8-25% ±(0.15%+5% of reading)

Not defined

ENF 0-8%

8-25% ±(0.15%+5% of reading)

Not defined

ISO 0-8%

8-25% ±(0.15%+5% of reading)

Not defined

SEV 0-10%

10-25% ±(0.15%+5% of reading)

Not defined

DES 0-22%

22-25% ±(0.15%+5% of reading)

Not defined

Features

Display&resolution: 720P(1280*720),5.5 inch

Parameters Displayed: EtCO2,FiCO2, SpO2, RR, PR,AG

Indicators: Battery status, Sound-light alarm, SpO2 pulse pitch tone

Interface: USB2.0

Battery life: >12h

Dimension: 202mmx95mmx45mm

Weight: 595g

Power supply: 100-240V AC,50/60 Hz,15W

Built-in 9000mAh Li-ion battery

Trend information

Long term trend: 72h

Language

Language: English/Chinese

Classification

Product class: IIB
